The heat manager can also be changed to use PID which can yield better results after running the PID Tuning command for a set temperature. (PID is a control loop feedback mechanism with many uses. A general description of PID is beyond the scope of this article. ) Tune the PID control system to the temperature you most frequently use. Both the heat bed and blower fan were turned off. Note that this is the same test setup I used before I reset Marlin to defaults. First tune failed with 'PID Autotune failed! Temperature too high' - the temperature overshot by 20°C then stopped. Second tune I adjusted the PIDMAX value to 128 and ran again. Success with results P13.42 I0.68 D66.25.

Going from a finished print to a great print takes a lot of calibration steps. Besides having the heatbed leveled correctly, and the extruder perfectly calibrated to melt just enough filament, the temperature of the hotend and the heatbed is just as important. Today i am going to show you how to perform a PID Tuning to have constant and accurate temperatures during your prints.

What is PID Tuning?

Before starting with the guide on how to do a PID tuning, we fist need to understand the concept. In just a few words, PID is an algorithm that makes sure the heaters for both hotend and heatbed supply just enough heat in order to have the difference between the highest and lowest temperature as small as possible. If you are interested in learning more about what is PID, you can check this Wikipedia article where a PID controller is described Digital auto tuning sony bravia not working on iphone.

Prerequisites for 3D Printer PID Calibration

In order to perform a successful 3D printer PID tuning, you need to have the 3D printer connected to your computer via USB. Next, you need to access the terminal for your printer firmware. Today i will use Pronterface but anything will do, as long as you are able to send G-Code commands to the printer.

Hotend PID Tuning

Now that we have the 3D Printer connected to the computer, we can start the Hotend PID Calibration.

Running bed heat auto tune video
  1. Get the current PID settings using the M503command. Your printer will return the current PID settings.
  2. Run the M106 S255 command in order to set your cooling fan to 100%
  3. Run the M303 E0 S215 C8command and wait for the process to finish.

The message “PID Autotune start” will appear in the terminal. Your hotend will start to gradually heat and get new readings.

Hotend PID Tuning Pronterface

While the hotend PID Calibration is underway, let’s understand the command we ran.

Running Bed Heat Auto Tune Kit

M303 – This command initiates a process of heating and cooling to determine the proper PID values for the specified hotend or the heated bed.
E0 – This argument selects the extruder we want to calibrate. I have only one extruder, so i will set it to 0.
S215 – This argument sets the temperature for the extruder PID Calibration to 215C.
C8 – This argument sets the number of cycles we want to run. I selected 8 because it’s the recommended value in Marlin firmware, but any value from 3 to 10 is great.

Library on PHPoC will perform adjustment based on the feedback value, desired value, Kp, Ki and Kd gain, and staling factor. Relay auto tuning pid. DC motor sends the calculated value (called feedback value) back to PHPoC Blue or Black. The calculation of position and speed is performed by DC motor controller.

When the message “PID Autotune Finished” is displayed in the terminal window, the hotend PID Tuning is complete.

You will also see new Kp, Ki and Kd constants that need to be saved so let’s do that now. The previous values were so we need to adapt the command with the new values and save them.

  1. Run the M301 P24.36 I1.39 D106.76 command to add the new values
  2. Run M500 to save the values.
  3. Run M503 to check your current values. These should be the same as the values we just saved.

Save new Hotend PID settings

Heatbed PID Tuning

If you managed to perform the hotend calibration, then the heatbed PID Calibration will be much easier.

  1. Get the current PID settings using the M503command. Your printer will return the current PID settings for the heatbed.
  2. Run the M303 E-1 S60 C8command and wait for the process to finish.

The message “PID Autotune start” will appear in the terminal. Your heatbed will start to gradually heat and get new readings. While the heatbed PID calibration is underway, let’s understand the command we ran.

M303 – This command initiates a process of heating and cooling to determine the proper PID values for the specified hotend or the heated bed.
E-1 – This argument selects the heatbed we want to calibrate. I have only one heatbed, so i will set it to 1.
S60 – This argument sets the temperature for the heatbed PID Calibration to 60C.
C8 – This argument sets the number of cycles we want to run. I selected 8 because it’s the recommended value in Marlin firmware, but any value from 3 to 10 is great.
When the message “PID Autotune Finished” is displayed in the terminal window, the hotend PID Tuning is complete.

Running Bed Heat Auto Tune Machine

You will also see new Kp, Ki and Kd constants that need to be saved so let’s do that now. The previous values were so we need to adapt the command with the new values and save them.

  1. Run the M304 P824.78 I154.89 D1097.99 command to add the new values
  2. Run M500 to save the values.
  3. Run M503 to check your current values. These should be the same as the values we just saved.

Running Bed Heat Auto Tune For Sale

More information about PID Tuning can be found on the RepRap wiki
